Script

Commands Available for Scripts in BlueStacks

• tap

  tap x1 y1 x2 y2 …xn yn delay

  This does a tap gesture. Single or multiple touchpoints can be specified. The touchpoint(s) are held for a specified delay. If the delay is not specified it is assumed to be 50msec.

  Up to 16 touchpoints are supported. But keep in mind that other touchpoints from other controls are aggregated before sending to android.

• swipe

  swipe x1 y1 x2 y2… xn yn delay

  e.g.

  # swipe 4,5 to 40,45

  # take 100msecs

  swipe 4 5 40 45 100

  Do a swipe gesture. Multiple points may be specified which the swipe goes through.

  Delay is specified in milliseconds. This is the amount of time the entire swipe gesture takes.

• loop / loopEnd

  loop n

  .

  .

  loopEnd

  Commands following loop command until loopEnd are executed n times.

  If n is not specified the loop continues indefinitely or until the macro trigger key is released.

• onRelease

  onRelease

  This provides finer control over the execution of the script. A different set of commands can be provided for executing when the trigger key is pressed and released.

  All commands from the top of the script until the onrelease command are executed when trigger key is pressed. Commands following the onRelease command are executed when the trigger key is released.

• enterShoot

  enterShoot

  Enter shooting mode used to play FPS games. If a Pan control does not exist in the current scheme this is ignored. If shooting mode is already enabled this has no effect.

• exitShoot

  exitShoot

  Exit shooting mode. If a Pan control does not exist in the current scheme this is ignored. If shooting mode is disabled this is ignored.

• toggleShoot

  toggleShoot

  Toggle shooting mode. If a Pan control does not exist in the current scheme this is ignored.

• #

  # this is a comment

  Comments begin with #. Everything until the end of the line is considered comment and is ignored. A comment can be on a line by itself or can be placed at the end of a command on the same line.

• keyDown

  keyDown key

  e.g.

  keyDown TAB

  Exit shooting mode. If a Pan control does not exist in the current scheme this is ignored. If shooting mode is disabled this is ignored.

• keyDown2

  keyDown2 key

  e.g.

  keyDown2 TAB

  Key is pressed and is not released until the keyup is encountered for the same key.

  Mapping is not executed and key down input is forwarded to android.

• keyUp

  keyUp key

  e.g.

  keyUp TAB

  Key is released. Mapping is executed if one exists; otherwise, key up input is forwarded to android.

• keyUp2

  keyup2 key

  e.g.

  keyUp2 TAB

  Key is released. Mapping is not executed and key up input is forwarded to android.

• mouseDown

  mouseDown x y

  e.g.

  mouseDown 44.0 55.5

  Mouse left button is pressed at location x, y. All locations are in screen percentages so that the same script can work across different resolutions.

• mouseUp

  mouseUp

  Mouse left button is released. No coordinates are required.

• mouseMove

  mouseMove x y

  e.g.

  mouseMove 4.56 5.67

  Mouse moves to new location x, y

• touch

  touch x1 y1 x2 y2 x3 y3

  e.g.

  # 3 fingers

  touch 4 5 6 7 8 9

  # 3rd finger lifted

  touch 4 5 6 7

  # fingers 1 and 2 move

  touch 5 6 7 8

  # fingers 1 and 2 lifted

  touch

  Touch input with the current set of touchpoints specified. Series of touch commands can be used to create arbitrary multi-touch input.

  Up to 16 touchpoints are supported. But keep in mind that other touchpoints from other controls are aggregated before sending to android.

• text

  text 'text'

  text backspace 2

  e.g.

  text “hello world”

  Send text input to android. This can be in any language.

  The format should be utf8.

• mouseWheel

  mouseWheel x y d

  mouseWheel 44.0 55.5 1

  mouseWheel 44.0 55.5 -1

  Send mouseWheel event to keymapping which will convert it to zoom or scroll accordingly

• wait

  wait msecs

  e.g.

  wait 24

  Waits for a specified number of milliseconds before executing the next command.
